The scope of application
Applied to illumination of water dripping, water splattering, water coagulation place in ships, such as oven cabin, dry cabin, tunnel, pipeline and weather deck etc
Products characteristic
1. The shell adopts good quality steel plate tensioned, lampshade adoptsinjection of PC, and has the seal structure
2. In order to prevent from electric shocking, equipped with a copper earthingrod with the mark in the lights
3. Plug-in type lamp holder, equipped wiring terminal inside, convenient to connect
4. The lamp equipped B15d lamp holder, used for 24V/15W emergency bulb,the edge of lampshade marks the marking, remark clear that need theemergency device when order.
5. Equipped compensating capacitance inside the lamp, also has the goodeffect of start
Adopt standard
Conform to CB/T3857-1999 standard
Production authentication
Approval by CCS(China Classification Society), certificate number00515Q20619ROM.
Type | L | L1 | H |
JCY22-2 | 692 | 480 | 134 |
JCY22-2E | 134 | ||
JCY22-2EF | 155 | ||
JCY32-2 | 992 | 700 | 134 |
JCY32-2E | 134 | ||
JCY32-2EF | 155 | ||
JCY42-2 | 1299 | 700 | 134 |
JCY42-2E | 134 | ||
JCY42-2EF | 155 |
Model
|
Power
|
Voltage
|
Power factor
|
Lamp holder
|
Protection class
|
Weight
|
Remark
|
JCY22-2
|
2×20W
|
110V/60HZ
|
0.85
|
G13
|
IP55
|
5.2kg
|
|
JCY22-2E
|
220V/50HZ | 5.3kg | with emergency | ||||
JCY22-2EF | 220V/60HZ | 6.9kg | with emergency and mesh cover | ||||
JCY32-2 | 2×30W | 110V/60HZ | 0.85 | G13 | IP55 | 9.1kg | |
JCY32-2E | 220V/50HZ | 9.2kg | with emergency | ||||
JCY32-2EF | 220V/60HZ | 10.0kg | with emergency and mesh cover | ||||
JCY42-2 | 2×40W | 110V/60HZ | 0.85 | G13 | IP55 | 9.3kg | |
JCY42-2E | 220V/50HZ | 9.4kg | with emergency | ||||
JCY42-2EF | 220V/60HZ | 10.2kg | with emergency and mesh cover |
Model | JCY22-2L | JCY23-2L |
IMPA Code | 791951-791952 | |
Wattage | 36W | |
Voltage | DC85-265V | |
Power factor | >0.85 | |
Material | Steel | |
Protection class | IP56 | |
Cable outside diameter | Φ12-Φ16 |
