SD512-3-140 Marine Battery Charger

Item No.: 02828
SD 512-3 marine battery charger is a fully automatic battery managing and charging system controlled by a microprocessor. It can be used to charge and maintain all types of 24 volt batteries.
Description
Description
SD512-3-140 Marine Battery Charger


SD 512-3 marine battery charger is a fully automatic battery managing and charging system controlled by a microprocessor. It can be used to charge and maintain all types of 24 volt batteries.
This smart charger contains an innovative 4-stage charging technology that applies an optimum charging process to your battery to maximize your battery’s life! The four charging stages are trickle, bulk, absorption, and float. The trickle stage safely charges overly discharged batter(the yellow light is on and the green light is flashing)and protects a damaged or shorted battery from excessive current. When the battery voltage reaches 18V or higher, the bulk stage is started by applying a constant current to restore the maximum battery charge level in the shortest time. When the battery voltage reaches about 28.4V, the charger starts the absorption stage that applies a constant voltage to the battery to bring the battery to 100% capacity. When the battery is fully charged, the green light is on. Then, the float stage tailors the constant voltage output to maintain the battery at full capacity while serving DC operated loads.

Specifications:

Model SD512-3/120, SD512-3/130, SD512-3/160, SD512-3/220, SD512-3/230, SD512-3/260, etc…
Yellow Lamp: charging, SD512-3 will charge automatically if the voltage of the battery is lower.
Green Lamp: fully charged, SD512-3 will stop charge automatically if the voltage of the battery is charged to full.
Red Lamp: failure, SD512-3 red lamp will flash there is open circuit, reverse polarity, short circuit.
Main Voltage: AC220V
Charge Voltage: DC12V, DC24V
Charge Current: 5A,10A,20A, 30A, 60A, etc…
Protection: IP56
Trouble Shooting: SD512-3 red light is on, no battery connection, wrong polarity, short circuited battery cables.
Warning: Always disconnect 42VAC before connecting or disconnecting batteries.
Working Temperature: -25 ~ 40
HS Code: 8504409999
Dimension: 280 x 222 x 117 mm
Weight: 4 - 6kg
Class Certificate: CCS/CE
