45T8/45T9/45L8/45L9 Marine Generator Synchronous Indicator

Item No.: 02589
Advanced converter line and Indicating device integration structure,the instrument is high accuracy and large angle.Null meter reading instrument all have zero button,easy to adjust.
Description
Description

45T8/45T9/45L8/45L9 Marine Generator Synchronous Indicator

1.Type:45T8、45T9、45L8、45L9
2.lt is mainly used in the grid connected operation of generator sets in various ship power stations .
3.The lampsynchroscope is applied for indication of phase and voltage accordance between generator and busbar.
4.Pointer synchronous meter voltage: AC90-110V。
5.Frequencyrange:50HZ,60HZ。
6.Ambient temperature range:-25℃ to +55℃。
7.Housing protection: IP44。
8.Vibration resistance: 2-100HZ≤0.7g。
9. Dielectric test: Ac2.6KV,50HZ, 1min。
10.Consumption:≤5VA。
