ABS/BV/CCS Marine Airtight Door For Sale

Manufactured according to IMO, SOLAS

Designed according to international standards with low noisy and light opening

Application: normally used in wheelhouse, suitable for vessels with low combustion point

Material: aluminum(type B)/stainless steel(type A)/steel frame and aluminum panel(type C)

Pressure difference: 100pa

Available certificates: GL, DNV, CCS, BV,ABS, LR, KR, RS, etc

Available in natural finish, primed or coated in accordance with client request.

Sizes and colors will customize according to your requirements.

•
  Specification of gastight door:
  1.Basic Parameters of A60 Weathertight and Gas Tight Door (Type A)


  TYPE	SIZE OF DOORWAY L*B	FRAME SIZE L1*B1	SIZE OF B.H. OPENING L2*B2	WEIGHT KG	OPTION
  SINGLE LEAF 262WHL005M-00	1600*600	1700*700	1705*705	118	DOOR CLOSER  DOOR STOPPER
  	1650*650	1750*750	1755*755	128
  	1700*700	1800*800	1805*805	142
  	1750*800	1850*900	1855*905	149
  	1900*900	2000*1000	2005*1005	162
  DOUBLE LEAF 262WHL005MS-00	1600*1000	1700*1100	1705*1105	172
  	1650*1100	1750*1200	1755*1205	184
  	1700*1300	1800*1400	1805*1405	230
  	1750*1600	1850*1700	1855*1705	280
  	2000*1850	2100*1950	2105*1955	324



    2.    Basic Parameters of A60 Weathertight and Gas Tight Door (Type B C)
