Nominal Dia.(mm) | Dimension(mm) | Wire Rope Dia.(mm) | |||||||
H | h | B | D | D1 | D2 | D3 | Weight(kg) | ||
150 | 480 | 280 | 460 | 165 | 114 | 206 | 158 | 33 | 16 |
200 | 560 | 320 | 520 | 216 | 165 | 256 | 206 | 60 | 22 |
250 | 640 | 360 | 610 | 267 | 216 | 308 | 256 | 102 | 28 |
300 | 680 | 380 | 660 | 318 | 267 | 360 | 308 | 154 | 34 |
350 | 720 | 420 | 720 | 355 | 267 | 400 | 312 | 186 | 38 |
