KL-1AG Alarm With Light And Buzzer

Item No.: 02734
The Telegraph System KED series is designed for sending and answering rotation rate and execution status of the main engine between wheelhouse and engine room. lt's agood choice for all kinds of vessels as main engine telegraph and spare engine telegraph.
Description
Description

KL-1AG Alarm With Light And Buzzer

Power supply: KL-1AG DC24V
Color: green gray(RAL 6034)
IP class: IP44
Weight: 0.92
Sound pressure level: 90dB~105dB
Passive contact load (resistance): 2A/30VDC 1A/125VAC
Passive contact maximum switchover voltage: 240VAC/120VDC
Stuffing box cable entrance hole size: 2-Φ12mm
Power: 5W
