Nomina Weight | Size | Proof test(kn) | |||||||
A | B | C | D | E | F | G | H | ||
200 | 789 | 495 | 566 | 182 | 847 | 313 | 110 | 145 | 61 |
300 | 900 | 566 | 648 | 207 | 968 | 358 | 136 | 175 | 80 |
400 | 994 | 624 | 710 | 231 | 1065 | 395 | 151 | 192 | 98 |
500 | 1070 | 670 | 765 | 250 | 1150 | 425 | 163 | 215 | 116 |
550 | 1105 | 693 | 790 | 257 | 1185 | 438 | 163 | 215 | 125 |
600 | 1138 | 714 | 815 | 263 | 1220 | 452 | 163 | 215 | 132 |
650 | 1170 | 733 | 835 | 275 | 1255 | 465 | 174 | 235 | 140 |
700 | 1200 | 750 | 860 | 275 | 1285 | 475 | 174 | 235 | 149 |
750 | 1225 | 765 | 875 | 275 | 1310 | 485 | 174 | 235 | 158 |
800 | 1253 | 780 | 895 | 281 | 1340 | 495 | 174 | 235 | 166 |
850 | 1280 | 800 | 915 | 295 | 1370 | 507 | 200 | 255 | 175 |
900 | 1300 | 810 | 927 | 297 | 1386 | 513 | 200 | 255 | 182 |
950 | 1327 | 830 | 950 | 308 | 1425 | 527 | 200 | 255 | 191 |
1000 | 1350 | 840 | 965 | 315 | 1450 | 536 | 200 | 255 | 199 |
1100 | 1394 | 875 | 1000 | 320 | 1490 | 555 | 215 | 280 | 216 |
1200 | 1435 | 900 | 1030 | 330 | 1540 | 570 | 215 | 280 | 231 |
1300 | 1475 | 925 | 1055 | 341 | 1580 | 585 | 215 | 280 | 247 |
1400 | 1510 | 945 | 1080 | 350 | 1620 | 600 | 215 | 280 | 262 |
1500 | 1545 | 970 | 1100 | 365 | 1660 | 610 | 215 | 280 | 278 |
1600 | 1578 | 990 | 1130 | 366 | 1690 | 627 | 236 | 310 | 292 |
1700 | 1608 | 1008 | 1150 | 373 | 1725 | 638 | 236 | 310 | 307 |
1800 | 1640 | 1030 | 1175 | 380 | 1760 | 650 | 236 | 310 | 321 |
1900 | 1670 | 1050 | 1190 | 390 | 1790 | 660 | 236 | 310 | 335 |
2000 | 1700 | 1065 | 1220 | 390 | 1825 | 675 | 236 | 310 | 349 |
2200 | 1750 | 1100 | 1250 | 410 | 1880 | 695 | 256 | 340 | 376 |
2400 | 1800 | 1130 | 1290 | 420 | 1940 | 717 | 279 | 340 | 401 |
2600 | 1855 | 1160 | 1330 | 420 | 1990 | 737 | 279 | 380 | 427 |
2800 | 1900 | 1190 | 1365 | 435 | 2040 | 755 | 279 | 380 | 450 |
3000 | 1950 | 1220 | 1400 | 445 | 2090 | 770 | 284 | 380 | 474 |
3250 | 2000 | 1250 | 1430 | 460 | 2140 | 790 | 284 | 385 | 506 |
3500 | 2050 | 1285 | 1470 | 470 | 2200 | 810 | 305 | 385 | 528 |
4000 | 2132 | 1340 | 1530 | 490 | 2280 | 850 | 310 | 410 | 577 |
4500 | 2224 | 1395 | 1590 | 510 | 2385 | 880 | 343 | 410 | 622 |
5000 | 2335 | 1460 | 1670 | 540 | 2505 | 927 | 343 | 450 | 661 |
5300 | 2350 | 1470 | 1680 | 540 | 2520 | 930 | 343 | 450 | 685 |
5800 | 2430 | 1525 | 1745 | 560 | 2610 | 965 | 370 | 450 | 721 |
6000 | 2484 | 1555 | 1780 | 575 | 2665 | 986 | 370 | 480 | 735 |
6500 | 2520 | 1580 | 1810 | 580 | 2710 | 1002 | 370 | 480 | 767 |
7000 | 2580 | 1610 | 1840 | 595 | 2755 | 1020 | 377 | 480 | 804 |
7400 | 2635 | 1650 | 1890 | 605 | 2825 | 1045 | 391 | 500 | 832 |
8000 | 2686 | 1685 | 1930 | 615 | 2880 | 1065 | 391 | 540 | 877 |
8300 | 2736 | 1710 | 1950 | 635 | 2926 | 1085 | 391 | 540 | 900 |
8800 | 2785 | 1745 | 1995 | 643 | 2990 | 1105 | 418 | 540 | 936 |
9200 | 2830 | 1775 | 2030 | 650 | 3030 | 1120 | 418 | 580 | 961987 |
9600 | 2877 | 1800 | 2060 | 660 | 3080 | 1140 | 437 | 580 | 1010 |
10000 | 2920 | 1830 | 2090 | 670 | 3126 | 1157 | 600 | 1040 |
